Aluminium trilmotor KBM-2,5-2 2/4V-3f 3000rpm Mdyn 2.5kgcm Fcen 1.23kN Pnom 0.18kW
| Product code | KBM00AA00025 |
|---|---|
| Manufacturer code | KBM-2,5-2 |
| Power supply motor | 230/400V-3phase-50Hz |
| Dynamic torque | 2.5 kgcm |
| Centrifugal force | 1.23 kN |
| Rated power | 0.18 kW |
To download the product sheet you need to be logged in. Click here to login.
| manufacturer | Koolen Industry |
|---|---|
| material housing | Aluminum |
| number of poles | 2 |
| rated power | 0.18 kW |
| power supply motor | 230/400V-3phase-50Hz |
| iP protection class | 66 |
| rated current | 0.35 A |
| breakaway current / Rated current Ia/In | 2.7 |
| dynamic torque | 2.5 kgcm |
| static torque | 1.25 kgcm |
| centrifugal force | 1.23 kN |
| pTC temperature controller | No |
| size gland | M16x1.5 |
| number of cable glands | 1 |
| weight | 4.95 kg |
| color | Blue |
| depth | 150 mm |
| height | 150 mm |
| length | 212 mm |
| bolt size | M8 |
| number of bolts | 4 |
Drawing
The vibration motors of Koolen Industry is for more than 40 years an established name in the vibration technology market. De KB-series is a three-phase vibration motor. Most frame sizes can be delivered with ATEX certification. The vibration motors are applied to thicken, transporter and loading of bulk materials. De manufacturing and selection of vibration motors requires dedicated knowledge. Our product specialists are at your service to calculate and select the proper vibration for you.
Rated power
- 0.075 – 18.7 kW
Number of poles
- 2, 4, 6, 8
Dynamic torque
- 1.3 – 5823 kgcm
Centrifugal force
- 0.24 – 226 kN
Power supply
- 3-phase – 230V or 400V AC
- Special voltages on request
Housing
- Aluminum or cast-iron
Cover
- Powder coated sheet metal
- Optionally stainless steel cover
ATEX
- Most of the frame sizes with following ATEX certification
- 3G EEx nA II T3
- II sD IP65 T120 °C
- According to CESI 03ATEX274
